Description

MoTeC’s 5 Button Rotary Controller simplifies and centralises control within the cockpit, reducing the number of switches and dials required to make adjustments on the fly. It integrates with MoTeC Display Loggers, providing configurable functionality with a standard system and intuitive operation with MoTeC's Colour Display Menu System when Display Creator is installed.

The controller features a Menu button, a Back button and three user-definable buttons that can be labelled with the supplied stickers for a professional finish. The rotary dial itself is large and ergonomically designed with distinct increments during rotation. It is easy to grip and turn with precision, even while wearing gloves, enabling the driver or co-driver to operate the controller primarily by feel.

Specifications

  • Small, lightweight and ergonomically designed
  • Rugged - vibration and impact resistant for use in extreme environments
  • Dust and water resistant - sealed to IP67
  • 5 x Backlit buttons:
    • 1 x Menu
    • 1 x Back
    • 3 x User-defined (blank when supplied)
  • Large selection of semi-transparent adhesive labels included
  • Compatible with MoTeC's Colour Display Menu System:
    • Turn the dial to scroll through menu structures
    • Press the dial to make a selection

Configuration

  • The device comes preconfigured for use with MoTeC Colour Display Loggers.

Communications

  • Single CAN bus

Capacity on CAN bus

  • Up to 2 Rotary Controllers

Power

  • Operating voltage: 8 to 32 V DC
  • Operating current: 0.2 A maximum
  • Reverse battery protection
  • Short circuit protection

Compatibility

  • Universal Part

MoTeC’s 5 Button Rotary Controller simplifies and centralises control within the cockpit, reducing the number of switches and dials required to make adjustments on the fly. It integrates with MoTeC Display Loggers, providing configurable functionality with a standard system and intuitive operation with MoTeC's Colour Display Menu System when Display Creator is installed.

The controller features a Menu button, a Back button and three user-definable buttons that can be labelled with the supplied stickers for a professional finish. The rotary dial itself is large and ergonomically designed with distinct increments during rotation. It is easy to grip and turn with precision, even while wearing gloves, enabling the driver or co-driver to operate the controller primarily by feel.

  • Small, lightweight and ergonomically designed
  • Rugged - vibration and impact resistant for use in extreme environments
  • Dust and water resistant - sealed to IP67
  • 5 x Backlit buttons:
    • 1 x Menu
    • 1 x Back
    • 3 x User-defined (blank when supplied)
  • Large selection of semi-transparent adhesive labels included
  • Compatible with MoTeC's Colour Display Menu System:
    • Turn the dial to scroll through menu structures
    • Press the dial to make a selection

Configuration

  • The device comes preconfigured for use with MoTeC Colour Display Loggers.

Communications

  • Single CAN bus

Capacity on CAN bus

  • Up to 2 Rotary Controllers

Power

  • Operating voltage: 8 to 32 V DC
  • Operating current: 0.2 A maximum
  • Reverse battery protection
  • Short circuit protection
  • Universal Part
