Description

Cutting 1/1000th of a second with S tires

  • monotube shock absorber
  • 24-step damping force adjustment ? 3-way adjustment
  • Rebound: 24-step damping force adjustment
  • Compression side: 24-step low-speed damping force adjustment, 24-step high-speed damping force adjustment
  • Newly developed CUSCO SPORT "Blue spring" adopted
  • Full length adjustable vehicle height adjustment
  • Equipped with a separate tank
  • Pillow ball upper mount standard equipment * Excluding some models
  • Ram type (inverted type) shock absorber
  • *Front strut type only
  • Compatible with S tires

Specifications

  • Recommended Ride Height Range (mm): Front -65 to -20; Rear -60 to 0
  • Max Ride Height Range (mm): Front -65 to -20; Rear -60 to 0
  • Dumping Force: 24 steps, 3way
  • Default Height (mm): -40 / -35
  • Spring Rate (kgf/mm): Front 16 or (12/14/18/20/22/24); Rear 16 or (12/14/18/20/22/24)
  • Height Adjust: Front Full-length Adjustable; Rear Full-length Adjustable
  • Upper mount: Front Non-adjustable pillow ball upper mount; Rear Non-adjustable pillow ball upper mount

Compatibility

  • 1991-2002 Mazda RX-7 FD3S

Cutting 1/1000th of a second with S tires

  • monotube shock absorber
  • 24-step damping force adjustment ? 3-way adjustment
  • Rebound: 24-step damping force adjustment
  • Compression side: 24-step low-speed damping force adjustment, 24-step high-speed damping force adjustment
  • Newly developed CUSCO SPORT "Blue spring" adopted
  • Full length adjustable vehicle height adjustment
  • Equipped with a separate tank
  • Pillow ball upper mount standard equipment * Excluding some models
  • Ram type (inverted type) shock absorber
  • *Front strut type only
  • Compatible with S tires
  • Recommended Ride Height Range (mm): Front -65 to -20; Rear -60 to 0
  • Max Ride Height Range (mm): Front -65 to -20; Rear -60 to 0
  • Dumping Force: 24 steps, 3way
  • Default Height (mm): -40 / -35
  • Spring Rate (kgf/mm): Front 16 or (12/14/18/20/22/24); Rear 16 or (12/14/18/20/22/24)
  • Height Adjust: Front Full-length Adjustable; Rear Full-length Adjustable
  • Upper mount: Front Non-adjustable pillow ball upper mount; Rear Non-adjustable pillow ball upper mount
  • 1991-2002 Mazda RX-7 FD3S
