Description

Low-down ride comfort and quietness are top-level. "Damping force 40-step adjustment" and "full-length adjustable vehicle height adjustment" provide optimal ride comfort regardless of the amount of low-down and fine-tuned vehicle height adjustment of the street series.

  • 40 steps of damping force adjustment
  • Full length adjustable vehicle height adjustment
  • Upper mount standard equipment
  • (except models with upper mountless structure)
  • The minivan is standard equipped with a genuine shape rubber upper mount with high quietness.
  • Adopted CPRV (Pressure Control Valve)
  • Silent design that suppresses the operating sound (squeaky sound) of damping adjustable shocks
  • Compatible with e-con2
  • (Applicable models only)

Specifications

  • Dumping Force: 40 steps
  • Recommended Ride Height Range (mm): Front -50 to -20; Rear -40 to -20
  • Max Ride Height Range (mm): Front -50 to 0; Rear -45 to -10
  • Default Height (mm): -40 / -40
  • Spring Rate (kgf/mm): Front 5 or (4); Rear 4
  • Height Adjust: Front Full-length Adjustable; Rear Threaded spacer
  • E-CON2: Compatible

Compatibility

  • 2017+ Suzuki Swift Sport ZC33S K14C

Low-down ride comfort and quietness are top-level. "Damping force 40-step adjustment" and "full-length adjustable vehicle height adjustment" provide optimal ride comfort regardless of the amount of low-down and fine-tuned vehicle height adjustment of the street series.

  • 40 steps of damping force adjustment
  • Full length adjustable vehicle height adjustment
  • Upper mount standard equipment
  • (except models with upper mountless structure)
  • The minivan is standard equipped with a genuine shape rubber upper mount with high quietness.
  • Adopted CPRV (Pressure Control Valve)
  • Silent design that suppresses the operating sound (squeaky sound) of damping adjustable shocks
  • Compatible with e-con2
  • (Applicable models only)
  • Dumping Force: 40 steps
  • Recommended Ride Height Range (mm): Front -50 to -20; Rear -40 to -20
  • Max Ride Height Range (mm): Front -50 to 0; Rear -45 to -10
  • Default Height (mm): -40 / -40
  • Spring Rate (kgf/mm): Front 5 or (4); Rear 4
  • Height Adjust: Front Full-length Adjustable; Rear Threaded spacer
  • E-CON2: Compatible
  • 2017+ Suzuki Swift Sport ZC33S K14C
