Description

The DB1766SS Street Series brake pads are the latest addition to DBA’s comprehensive range of braking products. Aimed at the OE replacement market, the range was developed with three technical objectives in mind – create a brake pad that performs at OE level or better, offers the best friction formulation for the application, and complements DBA’s long-established, market-leading range of Street Series disc rotors.

Great attention was given to the development of the friction formulation to achieve a friction coefficient that outperforms the current market standard. Consequently, DBA did not settle on just one formulation, but offers either ceramic or semi-metallic formulations depending on application and required performance.

Replacing your brake rotors? DBA recommends use with STREET SERIES plain or T2 slotted disc rotors for increased first application effectiveness and reducing bed-in time.

Features:

  • OE-style post-cured process for optimal braking performance over the pad life
  • Ceramic formulation and copper-free (NSFI certified) for low dust emission & clean wheels
  • High-friction stripe for easy bedding-in
  • Application-specific NVH shims, slots and chamfers for less vibration and noise

Ideal for:

  • OE replacement & everyday use
  • Passenger cars & SUVs
  • Light commercial Vehicles
  • Use with DBA Street Series Disc Rotors
Set ContainsPad Overall Length mmPad Overall Height mmPad Thickness mm
LH Inner + RH Inner + 2 Outer Pads121.15114.9

Specifications

Brake Type:Disc Brake
Length 1 [mm]:121,1
Thickness 1 [mm]:14,9
Width 1 [mm]:51

Compatibility

  • HOLDEN
  • COMMODORE
  • 2006 - 2013 Petrol Engine 6.0 i V8 SS, SS-V VE Sedan 260KW
  • 2006 - 2013 Petrol Engine 6.0 i V8 SS, SS-V VE Sedan 270KW
  • 2006 - 2013 Petrol Engine 3.6 i V6 SV6 VE Sedan 195KW
  • 2006 - 2013 Petrol Engine 3.6 i V6 Dual Fuel LPG VE Sedan 175KW
  • 2006 - 2013 Petrol Engine 3.6 i V6 VE Sedan 180KW
  • 2008 - 2013 Petrol Engine 3.6 i V6 VE Wagon 180KW
  • 2008 - 2013 Petrol Engine 3.6 i V6 VE Wagon 175KW
  • 2008 - 2013 Petrol Engine 3.6 i V6 SV6 VE Wagon 195KW
  • 2008 - 2013 Petrol Engine 6.0 i V8 SS, SS-V VE Wagon 270KW
  • 2009 - 2013 Petrol Engine 3.6 i V6 SV6 VE Ute 210KW
  • 2007 - 2013 Petrol Engine 3.6 i V6 VE Ute 175KW
  • 2007 - 2013 Petrol Engine 3.6 i V6 Dual Fuel LPG VE Ute 175KW
  • 2007 - 2013 Petrol Engine 6.0 i V8 SS, SS-V VE Ute 270KW
  • 2007 - 2010 Petrol Engine 6.0 i V8 SS, SS-V VE Ute 260KW
  • 2009 - 2013 Petrol Engine 3.6 i V6 SV6 VE Sedan 210KW
  • 2009 - 2013 Petrol Engine 3.0 i V6 VE Sedan 190KW
  • 2007 - 2013 Petrol Engine 3.6 i V6 VE Ute 180KW
  • 2009 - 2013 Petrol Engine 3.6 i V6 SV6 VE Ute 195KW
  • 2009 - 2013 Petrol Engine 3.0 i V6 VE Wagon 190KW
  • 2009 - 2013 Petrol Engine 3.6 i V6 SV6 VE Wagon 210KW
  • STATESMAN
  • 2006 - 2010 Petrol Engine 3.6 i V6 WM Sedan 195KW
  • CAPRICE
  • 2006 - 2013 Petrol Engine 3.6 i V6 WM Sedan 195KW
  • 2006 - 2013 Petrol Engine 6.0 i V8 WM Sedan 270KW
  • HSV
  • CLUBSPORT
  • 2008 - 2013 Petrol Engine 6.2 i V8 VE Sedan 317KW
  • MALOO
  • 2008 - 2013 Petrol Engine 6.2 i V8 VE Ute 317KW

The DB1766SS Street Series brake pads are the latest addition to DBA’s comprehensive range of braking products. Aimed at the OE replacement market, the range was developed with three technical objectives in mind – create a brake pad that performs at OE level or better, offers the best friction formulation for the application, and complements DBA’s long-established, market-leading range of Street Series disc rotors.

Great attention was given to the development of the friction formulation to achieve a friction coefficient that outperforms the current market standard. Consequently, DBA did not settle on just one formulation, but offers either ceramic or semi-metallic formulations depending on application and required performance.

Replacing your brake rotors? DBA recommends use with STREET SERIES plain or T2 slotted disc rotors for increased first application effectiveness and reducing bed-in time.

Features:

  • OE-style post-cured process for optimal braking performance over the pad life
  • Ceramic formulation and copper-free (NSFI certified) for low dust emission & clean wheels
  • High-friction stripe for easy bedding-in
  • Application-specific NVH shims, slots and chamfers for less vibration and noise

Ideal for:

  • OE replacement & everyday use
  • Passenger cars & SUVs
  • Light commercial Vehicles
  • Use with DBA Street Series Disc Rotors
Set ContainsPad Overall Length mmPad Overall Height mmPad Thickness mm
LH Inner + RH Inner + 2 Outer Pads121.15114.9
Brake Type:Disc Brake
Length 1 [mm]:121,1
Thickness 1 [mm]:14,9
Width 1 [mm]:51
  • HOLDEN
  • COMMODORE
  • 2006 - 2013 Petrol Engine 6.0 i V8 SS, SS-V VE Sedan 260KW
  • 2006 - 2013 Petrol Engine 6.0 i V8 SS, SS-V VE Sedan 270KW
  • 2006 - 2013 Petrol Engine 3.6 i V6 SV6 VE Sedan 195KW
  • 2006 - 2013 Petrol Engine 3.6 i V6 Dual Fuel LPG VE Sedan 175KW
  • 2006 - 2013 Petrol Engine 3.6 i V6 VE Sedan 180KW
  • 2008 - 2013 Petrol Engine 3.6 i V6 VE Wagon 180KW
  • 2008 - 2013 Petrol Engine 3.6 i V6 VE Wagon 175KW
  • 2008 - 2013 Petrol Engine 3.6 i V6 SV6 VE Wagon 195KW
  • 2008 - 2013 Petrol Engine 6.0 i V8 SS, SS-V VE Wagon 270KW
  • 2009 - 2013 Petrol Engine 3.6 i V6 SV6 VE Ute 210KW
  • 2007 - 2013 Petrol Engine 3.6 i V6 VE Ute 175KW
  • 2007 - 2013 Petrol Engine 3.6 i V6 Dual Fuel LPG VE Ute 175KW
  • 2007 - 2013 Petrol Engine 6.0 i V8 SS, SS-V VE Ute 270KW
  • 2007 - 2010 Petrol Engine 6.0 i V8 SS, SS-V VE Ute 260KW
  • 2009 - 2013 Petrol Engine 3.6 i V6 SV6 VE Sedan 210KW
  • 2009 - 2013 Petrol Engine 3.0 i V6 VE Sedan 190KW
  • 2007 - 2013 Petrol Engine 3.6 i V6 VE Ute 180KW
  • 2009 - 2013 Petrol Engine 3.6 i V6 SV6 VE Ute 195KW
  • 2009 - 2013 Petrol Engine 3.0 i V6 VE Wagon 190KW
  • 2009 - 2013 Petrol Engine 3.6 i V6 SV6 VE Wagon 210KW
  • STATESMAN
  • 2006 - 2010 Petrol Engine 3.6 i V6 WM Sedan 195KW
  • CAPRICE
  • 2006 - 2013 Petrol Engine 3.6 i V6 WM Sedan 195KW
  • 2006 - 2013 Petrol Engine 6.0 i V8 WM Sedan 270KW
  • HSV
  • CLUBSPORT
  • 2008 - 2013 Petrol Engine 6.2 i V8 VE Sedan 317KW
  • MALOO
  • 2008 - 2013 Petrol Engine 6.2 i V8 VE Ute 317KW
