Description

EnShield technology has been introduced to the Street Series range to provide corrosions resistant rotors, keeping the rotors looking good throughout service life.

The EnShield process begins with a zinc/aluminium water based coating being applied to the entire rotor surface and is then
baked on.

EnShield rotors are denoted by the suffix (E) in Street Series part numbers.



STREET SERIES direct replacement rotors are ideal for drivers seeking an OE level performance upgrade.

STREET SERIES rotors are the perfect option for drivers looking for a direct OE replacement disc rotor that is built using the highest quality manufacturing processes, materials and proven safety, thanks to DBAs over 40 years experience in braking.

We recommends STREET SERIES for daily drivers, light commercial and SUV applications.

Specifications

  • Product SubVariant En-Shield
    Axle Front
    Vane Design KP Vents
    Outer diameter[mm] 326
    Height [mm] 53
    Brake Disc Thickness [mm] 30
    Minimum Thickness [mm] 28
    Centering Diameter [mm] 58
    Number of Holes 10
    Pitch Circle Ø 100 & 114.3
    Uom Each
    Surface Design Plain

  • Surface Design Slots and/or chamfered drill holes facilitate the exit of friction dust and gasses, for a quieter and more responsive pedal feel.*
  • Anti Rust Painted non-friction areas to prevent rust and enhance appearance, or full En-shield coating to protect the rotor and alleviate the need for pre-installation cleaning.*
  • BI-Directional Use Symmetrical slotting and/or drilling for universal left/right use.*
  • Thermal Efficiency Centre-split core castings for increased heat transfer and thermal efficiency.
  • CBN CBN (Cubic Boron Nitride) machine turned finish, minimising disc thickness variation and the potential for pad “knock” and resulting premature wear.
  • Kangaroo Paw Unique Kangaroo Paw vane design for up to 20% better heat dissipation, increasing braking effectiveness and prolonging brake life.*

Compatibility

  • 2016 - 2021 Subaru BRZ ZC6 (2D Coupe) Base - FA20C 2.0L Aspirated Petrol RWD (152kW) 6AT
  • 2016 - 2021 Subaru BRZ ZC6 (2D Coupe) Base - FA20C 2.0L Aspirated Petrol RWD (152kW) 6MT
  • 2012 - 2016 Subaru BRZ ZC6 (2D Coupe) Base - FA20D 2.0L Aspirated Petrol RWD (147kW) 6AT
  • 2012 - 2016 Subaru BRZ ZC6 (2D Coupe) Base - FA20D 2.0L Aspirated Petrol RWD (147kW) 6MT
  • 2004 - 2007 Subaru Forester SG (4D Wagon) STI - EJ255 2.5L Turbo Petrol AWD (195kW) 6MT
  • 2016 - 2017 Subaru Forester SJ (4D Wagon) tS - FA20E 2.0L Turbo Petrol AWD (177kW) CVT
  • 2001 - 2005 Subaru Impreza GDB (4D Sedan) WRX STI - EJ207 2.0L Turbo Petrol AWD (206kW) 6MT
  • 2006 - 2007 Subaru Impreza GDF (4D Sedan) WRX STI - EJ257 2.5L Turbo Petrol AWD (206kW) 6MT
  • 2008 - 2014 Subaru Impreza GRF (4D Hatch) WRX STI - EJ257 2.5L Turbo Petrol AWD (221kW) 5AT
  • 2008 - 2014 Subaru Impreza GRF (4D Hatch) WRX STI - EJ257 2.5L Turbo Petrol AWD (221kW) 6MT
  • 2011 - 2014 Subaru Impreza GVF (4D Sedan) WRX STI - EJ257 2.5L Turbo Petrol AWD (221kW) 5AT
  • 2011 - 2014 Subaru Impreza GVF (4D Sedan) WRX STI - EJ257 2.5L Turbo Petrol AWD (221kW) 6MT
  • 2007 - 2008 Subaru Liberty BL9 (4D Sedan) GT-B STI - EJ255 2.5L Turbo Petrol AWD (194kW) 5AT
  • 2007 - 2008 Subaru Liberty BL9 (4D Sedan) GT-B STI - EJ255 2.5L Turbo Petrol AWD (194kW) 6MT
  • 2007 - 2008 Subaru Liberty BP9 (4D Wagon) GT-B STI - EJ255 2.5L Turbo Petrol AWD (194kW) 5AT
  • 2007 - 2008 Subaru Liberty BP9 (4D Wagon) GT-B STI - EJ255 2.5L Turbo Petrol AWD (194kW) 6MT
  • 2015 - 2017 Subaru WRX VAF (4D Sedan) STI - EJ257 2.5L Turbo Petrol AWD (221kW) 6MT
  • 2016 - 2021 Toyota 86 ZN6 (2D Coupe) GTS - FA20D 2.0L Aspirated Petrol RWD (152kW) 6AT
  • 2016 - 2021 Toyota 86 ZN6 (2D Coupe) GTS - FA20D 2.0L Aspirated Petrol RWD (152kW) 6MT

EnShield technology has been introduced to the Street Series range to provide corrosions resistant rotors, keeping the rotors looking good throughout service life.

The EnShield process begins with a zinc/aluminium water based coating being applied to the entire rotor surface and is then
baked on.

EnShield rotors are denoted by the suffix (E) in Street Series part numbers.



STREET SERIES direct replacement rotors are ideal for drivers seeking an OE level performance upgrade.

STREET SERIES rotors are the perfect option for drivers looking for a direct OE replacement disc rotor that is built using the highest quality manufacturing processes, materials and proven safety, thanks to DBAs over 40 years experience in braking.

We recommends STREET SERIES for daily drivers, light commercial and SUV applications.

  • Product SubVariant En-Shield
    Axle Front
    Vane Design KP Vents
    Outer diameter[mm] 326
    Height [mm] 53
    Brake Disc Thickness [mm] 30
    Minimum Thickness [mm] 28
    Centering Diameter [mm] 58
    Number of Holes 10
    Pitch Circle Ø 100 & 114.3
    Uom Each
    Surface Design Plain

  • Surface Design Slots and/or chamfered drill holes facilitate the exit of friction dust and gasses, for a quieter and more responsive pedal feel.*
  • Anti Rust Painted non-friction areas to prevent rust and enhance appearance, or full En-shield coating to protect the rotor and alleviate the need for pre-installation cleaning.*
  • BI-Directional Use Symmetrical slotting and/or drilling for universal left/right use.*
  • Thermal Efficiency Centre-split core castings for increased heat transfer and thermal efficiency.
  • CBN CBN (Cubic Boron Nitride) machine turned finish, minimising disc thickness variation and the potential for pad “knock” and resulting premature wear.
  • Kangaroo Paw Unique Kangaroo Paw vane design for up to 20% better heat dissipation, increasing braking effectiveness and prolonging brake life.*
  • 2016 - 2021 Subaru BRZ ZC6 (2D Coupe) Base - FA20C 2.0L Aspirated Petrol RWD (152kW) 6AT
  • 2016 - 2021 Subaru BRZ ZC6 (2D Coupe) Base - FA20C 2.0L Aspirated Petrol RWD (152kW) 6MT
  • 2012 - 2016 Subaru BRZ ZC6 (2D Coupe) Base - FA20D 2.0L Aspirated Petrol RWD (147kW) 6AT
  • 2012 - 2016 Subaru BRZ ZC6 (2D Coupe) Base - FA20D 2.0L Aspirated Petrol RWD (147kW) 6MT
  • 2004 - 2007 Subaru Forester SG (4D Wagon) STI - EJ255 2.5L Turbo Petrol AWD (195kW) 6MT
  • 2016 - 2017 Subaru Forester SJ (4D Wagon) tS - FA20E 2.0L Turbo Petrol AWD (177kW) CVT
  • 2001 - 2005 Subaru Impreza GDB (4D Sedan) WRX STI - EJ207 2.0L Turbo Petrol AWD (206kW) 6MT
  • 2006 - 2007 Subaru Impreza GDF (4D Sedan) WRX STI - EJ257 2.5L Turbo Petrol AWD (206kW) 6MT
  • 2008 - 2014 Subaru Impreza GRF (4D Hatch) WRX STI - EJ257 2.5L Turbo Petrol AWD (221kW) 5AT
  • 2008 - 2014 Subaru Impreza GRF (4D Hatch) WRX STI - EJ257 2.5L Turbo Petrol AWD (221kW) 6MT
  • 2011 - 2014 Subaru Impreza GVF (4D Sedan) WRX STI - EJ257 2.5L Turbo Petrol AWD (221kW) 5AT
  • 2011 - 2014 Subaru Impreza GVF (4D Sedan) WRX STI - EJ257 2.5L Turbo Petrol AWD (221kW) 6MT
  • 2007 - 2008 Subaru Liberty BL9 (4D Sedan) GT-B STI - EJ255 2.5L Turbo Petrol AWD (194kW) 5AT
  • 2007 - 2008 Subaru Liberty BL9 (4D Sedan) GT-B STI - EJ255 2.5L Turbo Petrol AWD (194kW) 6MT
  • 2007 - 2008 Subaru Liberty BP9 (4D Wagon) GT-B STI - EJ255 2.5L Turbo Petrol AWD (194kW) 5AT
  • 2007 - 2008 Subaru Liberty BP9 (4D Wagon) GT-B STI - EJ255 2.5L Turbo Petrol AWD (194kW) 6MT
  • 2015 - 2017 Subaru WRX VAF (4D Sedan) STI - EJ257 2.5L Turbo Petrol AWD (221kW) 6MT
  • 2016 - 2021 Toyota 86 ZN6 (2D Coupe) GTS - FA20D 2.0L Aspirated Petrol RWD (152kW) 6AT
  • 2016 - 2021 Toyota 86 ZN6 (2D Coupe) GTS - FA20D 2.0L Aspirated Petrol RWD (152kW) 6MT
