Description

Harmonics or high frequency fatigue is present in all racing engines and will usually destroy the valvetrain if not controlled. Properly designed valve springs will control the dominant harmonics, provide the needed stability, and reduce valvetrain component wear. Ferrea valve springs are developed from high strength alloys, including premium grade chrome silicon steel. Our springs are heat-treated and stress relieved, which dramatically increases the spring's life. Our valve springs provide the stability needed for high lift, high rpm racing engines, while minimizing the load loss for today's aggressive valvetrain combinations.

Specifications

  • Type/Material/Application: Dual Spring - Special Alloy - Turbo - Drag Racing
  • Outside Diameter: 20.8 mm/28 mm
  • Inside Diameter: 15.88mm/20.8mm
  • Seat Press:. 90lbs@36 mm
  • Open Press: 215 lbs@26 mm
  • Rate Inch: 317lbs
  • Coil Bind: 21.5 mm
  • Max Lift: 14 mm
  • This Spring requires Ferrea Titanium Retainer # E11065 and Ferrea Spring Seat Locator # SL1051 (Discard OEM Spring Seat Locator)

Compatibility

  • 2004 - 2008 Subaru WRX - EJ20
  • 2004 - 2008 Subaru STI

Harmonics or high frequency fatigue is present in all racing engines and will usually destroy the valvetrain if not controlled. Properly designed valve springs will control the dominant harmonics, provide the needed stability, and reduce valvetrain component wear. Ferrea valve springs are developed from high strength alloys, including premium grade chrome silicon steel. Our springs are heat-treated and stress relieved, which dramatically increases the spring's life. Our valve springs provide the stability needed for high lift, high rpm racing engines, while minimizing the load loss for today's aggressive valvetrain combinations.

  • Type/Material/Application: Dual Spring - Special Alloy - Turbo - Drag Racing
  • Outside Diameter: 20.8 mm/28 mm
  • Inside Diameter: 15.88mm/20.8mm
  • Seat Press:. 90lbs@36 mm
  • Open Press: 215 lbs@26 mm
  • Rate Inch: 317lbs
  • Coil Bind: 21.5 mm
  • Max Lift: 14 mm
  • This Spring requires Ferrea Titanium Retainer # E11065 and Ferrea Spring Seat Locator # SL1051 (Discard OEM Spring Seat Locator)
  • 2004 - 2008 Subaru WRX - EJ20
  • 2004 - 2008 Subaru STI
