Description

Product Notes:

  • A "Supercore" is a complete turbocharger, without a turbine housing fitted.
  • The GTX4709R Supercore fits directly into any existing GT4708R, GTX4708R, GT4718R and GTX4718R turbine housings.
  • This Turbocharger has a ported shroud/surge slotted compressor housing to increase surge resistance.

Specifications

  • Bearing Type: Ball Bearing
  • Cooling System: Oil Cooled Only
  • Horsepower: 1025-1950hp
  • Displacement: 2.5L - 10.0L Applications
  • GEN II compressor wheel aerodynamics
  • 9% increased flow
  • Larger .88 A/R compressor housing volute
  • GTX4720R features a 120mm comp exducer (+2mm) and has 30% lower inertia
  • Super core and turbine housing sold separately
  • Compatible with GT and GTX turbine housings
  • Lightweight Billet Backplate
  • NEW Backplate to Compressor Housing O-Ring
  • Speed Sensor Port compatible with the new flange style G-Sereis Speed Sensors

Compatibility

  • Universal Part

Product Notes:

  • A "Supercore" is a complete turbocharger, without a turbine housing fitted.
  • The GTX4709R Supercore fits directly into any existing GT4708R, GTX4708R, GT4718R and GTX4718R turbine housings.
  • This Turbocharger has a ported shroud/surge slotted compressor housing to increase surge resistance.
  • Bearing Type: Ball Bearing
  • Cooling System: Oil Cooled Only
  • Horsepower: 1025-1950hp
  • Displacement: 2.5L - 10.0L Applications
  • GEN II compressor wheel aerodynamics
  • 9% increased flow
  • Larger .88 A/R compressor housing volute
  • GTX4720R features a 120mm comp exducer (+2mm) and has 30% lower inertia
  • Super core and turbine housing sold separately
  • Compatible with GT and GTX turbine housings
  • Lightweight Billet Backplate
  • NEW Backplate to Compressor Housing O-Ring
  • Speed Sensor Port compatible with the new flange style G-Sereis Speed Sensors
  • Universal Part
