Description

When failure is not an option, this is the only spot light you need. ItÂ’s been designed from the ground up to take a hell of a beating, and itÂ’s got all the certifications to prove it.

Worried about vibration? Not a problem for this light: itÂ’s been tested to ensure it can survive 15G (R.M.S.) of vibration @ 24-2000Hz, meaning it will have no trouble with corrugations, bumps, holes, rocks or engine vibration.

What about impact? Again, not an issue. TheyÂ’ve been certified to IK08 standard, which means they can handle a severe impact without missing a beat.

Add to this the outstanding optoelectronic engineering that sees it produce a smooth, even 8° spot beam out to a forward distance of 1 lux at 270m, plus full compliance with all international standards, and you’ve got yourself a light without equal.

Specifications

  • Materials ADC12 cast aluminium housing / Pressure-formed polycarbonate lens
  • LED type 4 x 10W OSRAM®
  • Output 4,000 raw lumens
  • Distance 1 lux @ 270m
  • Beam type 8° spot
  • Ingress protection IP68 / IP69K
  • Impact rating IK08 (5J)
  • Vibration rating IEC 60068-2-6 & ISO16750-1 / (15G R.M.S. @ 24-2000Hz)
  • EMC rating CISPR 25 Class 3
  • Thermal shock rating IEC 60068-2-14 / (-40°C/85°C, 30 min, 40 cycles)
  • Working voltage 10-32V DC
  • Current draw 3.6A @ 12V / 1.8A @ 24V
  • Colour temperature 6000K
  • Dimensions 105mm (w) x 104mm (h) x 80mm (d)
  • Weight 0.78kg
  • LED Lifespan 50,000+ hours
  • Certifications CE, RoHS, EMC

What's Included

  • 1x 40W mine-spec square LED spot light with Deutsch lead
  • 1x Deutsch to DC adaptor
  • 1x 304 stainless steel bracket and fittings

Compatibility

  • Universal Part

When failure is not an option, this is the only spot light you need. ItÂ’s been designed from the ground up to take a hell of a beating, and itÂ’s got all the certifications to prove it.

Worried about vibration? Not a problem for this light: itÂ’s been tested to ensure it can survive 15G (R.M.S.) of vibration @ 24-2000Hz, meaning it will have no trouble with corrugations, bumps, holes, rocks or engine vibration.

What about impact? Again, not an issue. TheyÂ’ve been certified to IK08 standard, which means they can handle a severe impact without missing a beat.

Add to this the outstanding optoelectronic engineering that sees it produce a smooth, even 8° spot beam out to a forward distance of 1 lux at 270m, plus full compliance with all international standards, and you’ve got yourself a light without equal.

  • Materials ADC12 cast aluminium housing / Pressure-formed polycarbonate lens
  • LED type 4 x 10W OSRAM®
  • Output 4,000 raw lumens
  • Distance 1 lux @ 270m
  • Beam type 8° spot
  • Ingress protection IP68 / IP69K
  • Impact rating IK08 (5J)
  • Vibration rating IEC 60068-2-6 & ISO16750-1 / (15G R.M.S. @ 24-2000Hz)
  • EMC rating CISPR 25 Class 3
  • Thermal shock rating IEC 60068-2-14 / (-40°C/85°C, 30 min, 40 cycles)
  • Working voltage 10-32V DC
  • Current draw 3.6A @ 12V / 1.8A @ 24V
  • Colour temperature 6000K
  • Dimensions 105mm (w) x 104mm (h) x 80mm (d)
  • Weight 0.78kg
  • LED Lifespan 50,000+ hours
  • Certifications CE, RoHS, EMC
  • 1x 40W mine-spec square LED spot light with Deutsch lead
  • 1x Deutsch to DC adaptor
  • 1x 304 stainless steel bracket and fittings
  • Universal Part
