Harrop Engineering is proud to announce the launch of acomprehensive program involving the design and procurement of our own range ofUSA billet based camshafts and valve-train components.

The new camshaft range is a Harrop Engineering exclusive,utilising the experience gained during 60+ years of involvement at the leadingedge of automotive performance upgrades, with grind designs specific to the LSrange of engines as fitted to many VT to VF model Commodore and HSV models.

The H01 is the perfect camshaft upgrade for naturally aspirated applications, giving a you a nice lumpy idle and a healthy increase in engine performance, due to it's narrower LSA and longer duration. The H01 will work with standard diff ratio's but would see greater driving performance when coupled with 3.7 or 3.9:1 diff ratio. The H01 can be used in supercharged applications but boost pressure will be reduced due to the tighter LSA although this can be easily addressed by changing supercharger pulley size when the cam is installed.

Specifications

  • Duration @ 0.050”: 226°/232°
  • Maximum Lift @ Valve (1.7 Rocker Ratio): 0.607”/0.602”
  • Lobe Separation Angle (L.S.A.): 112°

Compatibility

  • Holden Commodore VT-VF models including H.S.V. variants fitted with LS series engines.

Harrop Engineering is proud to announce the launch of acomprehensive program involving the design and procurement of our own range ofUSA billet based camshafts and valve-train components.

The new camshaft range is a Harrop Engineering exclusive,utilising the experience gained during 60+ years of involvement at the leadingedge of automotive performance upgrades, with grind designs specific to the LSrange of engines as fitted to many VT to VF model Commodore and HSV models.

The H01 is the perfect camshaft upgrade for naturally aspirated applications, giving a you a nice lumpy idle and a healthy increase in engine performance, due to it's narrower LSA and longer duration. The H01 will work with standard diff ratio's but would see greater driving performance when coupled with 3.7 or 3.9:1 diff ratio. The H01 can be used in supercharged applications but boost pressure will be reduced due to the tighter LSA although this can be easily addressed by changing supercharger pulley size when the cam is installed.

  • Duration @ 0.050”: 226°/232°
  • Maximum Lift @ Valve (1.7 Rocker Ratio): 0.607”/0.602”
  • Lobe Separation Angle (L.S.A.): 112°
  • Holden Commodore VT-VF models including H.S.V. variants fitted with LS series engines.
