Description

The vision is for Kelford Cams to be known as one of the best in the camshaft industry, to be recognised worldwide for manufacturing high quality, high performance camshafts for the motorsport industry. We are a small company that, since 1968 has specialised in custom camshafts to suit the individual requirements of each racer. We have a vast knowledge of engine combinations for all types of motor sport and we know how to match camshafts to engine and vehicle requirements. All of our cams are manufactured in-house using ultra-modern design systems and ground using masterless CNC grinders with CBN cutting wheel technology for superior quality and consistency.

  • 284/280 Degrees advertised duration. 11.80mm /11.30mm lift
  • The ultimate cam for street, strip and track engines from 300-500hp. These camshafts are stable to 35lb boost and 8000 RPM with our recommended valve springs.

Specifications

Engine Make: Engine Model: Part Number:
HONDA B16A/B18C VTEC 176-B
Valve Clearance: Intake: 0.30mm Set HOT at the VALVE
  Exhaust: 0.30mm Set HOT at the VALVE

Cam Lift:   Intake: 7.81mm Exhaust: 7.48mm
Rocker Ratio:   Intake: 1.55 Exhaust: 1.55
Nett Valve Lift:   Intake: 11.80mm Exhaust: 11.30mm
Advertised Duration @ 0.10mm Intake: 284 Exhaust: 280
Duration @ 1.00mm VALVE LIFT Intake: 254 Exhaust: 248
Timing @ 1.00mm VALVE LIFT IVO: 23 BTDC EVO: 50 BBDC
    IVC: 51 ABDC EVC: 18 ATDC
Suggested Centre Lines:   Intake: 104 Exhaust: 106
VALVE Lift @ TDC Intake: 3.96mm Exhaust: 3.10



Compatibility

  • 1990-1993 Honda Integra LS DB1 Sedan
  • 1994-2001 Honda Integra RS/LS/SE/GS-DB7/DC4/DC3
  • 1994-2001 Honda Integra "RS/LS/GS/SE/(GSI Australia)" (DC4/DB7)
  • 1994-2001 Honda Integra AUDM/NZDM VTi-R
  • 1999-2001 Honda Integra AUDM/NZDM Type R

The vision is for Kelford Cams to be known as one of the best in the camshaft industry, to be recognised worldwide for manufacturing high quality, high performance camshafts for the motorsport industry. We are a small company that, since 1968 has specialised in custom camshafts to suit the individual requirements of each racer. We have a vast knowledge of engine combinations for all types of motor sport and we know how to match camshafts to engine and vehicle requirements. All of our cams are manufactured in-house using ultra-modern design systems and ground using masterless CNC grinders with CBN cutting wheel technology for superior quality and consistency.

  • 284/280 Degrees advertised duration. 11.80mm /11.30mm lift
  • The ultimate cam for street, strip and track engines from 300-500hp. These camshafts are stable to 35lb boost and 8000 RPM with our recommended valve springs.
Engine Make: Engine Model: Part Number:
HONDA B16A/B18C VTEC 176-B
Valve Clearance: Intake: 0.30mm Set HOT at the VALVE
  Exhaust: 0.30mm Set HOT at the VALVE

Cam Lift:   Intake: 7.81mm Exhaust: 7.48mm
Rocker Ratio:   Intake: 1.55 Exhaust: 1.55
Nett Valve Lift:   Intake: 11.80mm Exhaust: 11.30mm
Advertised Duration @ 0.10mm Intake: 284 Exhaust: 280
Duration @ 1.00mm VALVE LIFT Intake: 254 Exhaust: 248
Timing @ 1.00mm VALVE LIFT IVO: 23 BTDC EVO: 50 BBDC
    IVC: 51 ABDC EVC: 18 ATDC
Suggested Centre Lines:   Intake: 104 Exhaust: 106
VALVE Lift @ TDC Intake: 3.96mm Exhaust: 3.10



  • 1990-1993 Honda Integra LS DB1 Sedan
  • 1994-2001 Honda Integra RS/LS/SE/GS-DB7/DC4/DC3
  • 1994-2001 Honda Integra "RS/LS/GS/SE/(GSI Australia)" (DC4/DB7)
  • 1994-2001 Honda Integra AUDM/NZDM VTi-R
  • 1999-2001 Honda Integra AUDM/NZDM Type R
