Description

-Dual ball bearing system provides optimal turbo response & better durability by reducing the shaft-motion

-50*67mm 8 blade billet compressor wheel

-Gen2 cover integrated with the speed sensor port

-0.64, 0.86A/R T25 Inlet, 5 Bolt Outlet, 0.82 A/R dual V-BAND stainless steel Housing in option

Description

  • Compressor Wheel: 50*67mm
  • Turbine Wheel: 54/47mm
  • Compressor Inlet: 3? Hose
  • Compressor Outlet: 2? Hose
  • Turbine Inlet: T25 or 2.5? V-Band
  • Turbine Outlet: 5 Bolt or 3? V-Band (3.55 OD)
  • Oil Feed: -4 AN connect to the Oil Restrictor
  • Oil Drain: Std T3 Flange
  • Water In/Outlet: M14*1.5

We highly recommended running water cooling for better durability.

Specifications

Compatibility

  • Universal Part

-Dual ball bearing system provides optimal turbo response & better durability by reducing the shaft-motion

-50*67mm 8 blade billet compressor wheel

-Gen2 cover integrated with the speed sensor port

-0.64, 0.86A/R T25 Inlet, 5 Bolt Outlet, 0.82 A/R dual V-BAND stainless steel Housing in option

Description

  • Compressor Wheel: 50*67mm
  • Turbine Wheel: 54/47mm
  • Compressor Inlet: 3? Hose
  • Compressor Outlet: 2? Hose
  • Turbine Inlet: T25 or 2.5? V-Band
  • Turbine Outlet: 5 Bolt or 3? V-Band (3.55 OD)
  • Oil Feed: -4 AN connect to the Oil Restrictor
  • Oil Drain: Std T3 Flange
  • Water In/Outlet: M14*1.5

We highly recommended running water cooling for better durability.

  • Universal Part
