Description

  • Compact compressor cover
  • Dual Ceramic Ball Bearing System
  • 7+7 Blade Billet Compressor Wheel with Extended Tapered Tip Technology
  • Inconel 713c 9 Blade Turbine Wheel
  • Multiple options for turbine housing
  • V-Band Flange kit(s) for the exhaust housing included
  • Max Air Flow rate: 70 lb/min, rated @ 750 FWHP
  • Compressor Wheel: 62.5*82.4mm
  • Turbine Wheel: 68*62mm
  • Compressor Inlet: 3.0” Hose
  • Compressor Outlet: 2.0” Hose
  • Turbine Inlet: T3, T4, or 2.5? V-Band
  • Turbine Outlet: 3? V-Band (3.55?OD)
  • Oil Feed: -4 AN connect to the Oil Restrictor
  • Oil Drain: Std T3 Flange
  • Water In/Outlet: M14*1.5

    We highly recommended running water cooling for better durability.

    Specifications

    Compatibility

    • Universal Part
    • Compact compressor cover
    • Dual Ceramic Ball Bearing System
    • 7+7 Blade Billet Compressor Wheel with Extended Tapered Tip Technology
    • Inconel 713c 9 Blade Turbine Wheel
    • Multiple options for turbine housing
    • V-Band Flange kit(s) for the exhaust housing included
    • Max Air Flow rate: 70 lb/min, rated @ 750 FWHP
    • Compressor Wheel: 62.5*82.4mm
    • Turbine Wheel: 68*62mm
    • Compressor Inlet: 3.0” Hose
    • Compressor Outlet: 2.0” Hose
    • Turbine Inlet: T3, T4, or 2.5? V-Band
    • Turbine Outlet: 3? V-Band (3.55?OD)
    • Oil Feed: -4 AN connect to the Oil Restrictor
    • Oil Drain: Std T3 Flange
    • Water In/Outlet: M14*1.5

      We highly recommended running water cooling for better durability.

      • Universal Part
