Description

The L120 Enclosed Logger is a versatile, multipurpose device that can be used in a range of applications depending on which options are enabled. The device is compact and robust, and can be upgraded with increased levels of functionality, in the field, at any time.

L120 Uses:

D Series Display Controller
Any L120 can be used as a controller for any MoTeC D series display. The L120 can forward all of the channels required for the driver to the D153 or D175 , including lap timing, CAN and RS232 channels and much more.

Fully Featured Logger (with optional upgrades 29601 and 29619)
With the I/O and logging upgrades, the L120 can log any CAN and RS232 bus, as well as inputs wired directly to the box. This powerful logger can be placed anywhere in the vehicle, ensuring that the weight can be kept low and wiring to a minimum.

CAN and RS232 Logger (with optional upgrade 29619)
With the logging upgrade only, the L120 can be placed anywhere in the vehicle, and used to log any channels from both of the L120 CAN busses, as well as the RS232 bus. With only Power, CAN and RS232 connections, this is a simple to use enclosed logger.

T2 Telemetry Box (with optional upgrade 29621)
Using the L120 as a T2 box (optional upgrade) incorporates MoTeC's T2 telemetry system when you don't have a MoTeC colour display in the vehicle. The L120 with the T2 upgrade can receive messages from most other CAN units (such as non MoTeC ECUs and data loggers), convert it to a T2 data stream and transmit it out to the Radio for the pit side T2 system.

Can Bus Bridge
When the L120 is used without any upgrades, it can be used as a device that can take messages from one bus and pass it onto another. This is very useful where a vehicle has information that needs sharing, but the two CAN busses are incompatible, such as different bus speeds.



Specifications

Motec | 18039 | Data Acquistion & Display

  • Suitable for bikes, cars, marine and industrial applications
  • Supports Wideband Lambda from MoTeC PLMs or LTCs
  • Easily integrates with MoTeC CAN based products such as ECUs and expanders. Full I/O expansion available with use of E888, E816 expanders.
  • GPS Lap Timing
  • Supports T2 Telemetry

Logging - optional (requires logging upgrade)

  • 120 MB logging memory
  • Logging rates up to 500 samples per second
  • Fast Ethernet download
  • Includes i2 Standard data analysis software (Pro Analysis upgrade available)

Inputs

  • 2 Digital and 3 Speed inputs

Inputs -optional (requires I/O upgrade)

  • 6 analogue voltage inputs:
  • 4 x 0 to 5.46 V, 1.33 mV resolution
  • 2 x 0 to 15.0 V, 3.66 mV resolution
  • 2 analogue temperature inputs
  • 0 to 15 V, 3.66 mV resolution

Outputs - optional (requires I/O upgrade)

  • 4 low side outputs PWM or switched operation
  • 0.5 Amp max, current limited and thermal overload protected

Expanders

  • Compatible with E816 and E888 expanders (providing full functional use)

Internal Sensors

  • 3-axis accelerometer, detection range: +/-5G
  • Temperature sensor
  • Sensor supply voltage
  • Battery voltage

Communications

  • 2 configurable CAN buses, with individually programmable CAN bus speeds. One can be used as RS232 Receive.
  • 2 RS232 ports, one with transmit and receive, one with receive only

Power supply

  • Operating voltage: 6 to 32 V DC
  • Operating current: 0.4 A typical at 14 V (excluding sensor currents)
  • Reverse battery protection
  • Battery transient protection

Sensor supply currents

  • 5 V sensor supply: 0.25 A maximum
  • 8 V sensor supply: 0.25 A maximum

Operating temperature

  • Internal: -20 °C to 80 °C
  • Typical ambient temperature range in free air: -20 °C to 65 °C

Physical

  • Size: 134.5 x 103.9 x 20.2 mm excluding connector and tab
  • Weight 289 g
  • 1 x 34 pin waterproof connector

Compatibility

  • Universal Part
