Description

MoTeC's M1 ECU range begins a new era in engine control. The M1's unique technology redefines the meaning of customisation, delivering total control without compromise. Highly advanced security strategies make these ECU's ideal for both category managed and unrestricted applications.

Specifications

Motec | 13150M | Data Analysis

Injector

  • Peak and Hold Injector Outputs: 8
  • Low Side Injector Outputs: 6

Ignition

  • Outputs: 12

Auxiliary Outputs

  • Half Bridge: 10

Inputs

  • Universal Digital: 12
  • Digital: 4
  • Analogue Voltage: 17
  • Analogue Temperature: 6
  • Knock: 4
  • Lambda (narrow band):2

Data

  • CAN Bus: 3
  • RS232: 1
  • LIN: 1
  • Logging Memory: 250Mb

Physical

  • Dimensions: 162 x 127.5 x 40.5mm
  • Weight: 445g
  • Connector:
  • 2 x 34 Pin Plastic Connectors
  • 2 x 26 Pin Plastic Connectors

Compatibility

  • Universal Part

MoTeC's M1 ECU range begins a new era in engine control. The M1's unique technology redefines the meaning of customisation, delivering total control without compromise. Highly advanced security strategies make these ECU's ideal for both category managed and unrestricted applications.

Motec | 13150M | Data Analysis

Injector

  • Peak and Hold Injector Outputs: 8
  • Low Side Injector Outputs: 6

Ignition

  • Outputs: 12

Auxiliary Outputs

  • Half Bridge: 10

Inputs

  • Universal Digital: 12
  • Digital: 4
  • Analogue Voltage: 17
  • Analogue Temperature: 6
  • Knock: 4
  • Lambda (narrow band):2

Data

  • CAN Bus: 3
  • RS232: 1
  • LIN: 1
  • Logging Memory: 250Mb

Physical

  • Dimensions: 162 x 127.5 x 40.5mm
  • Weight: 445g
  • Connector:
  • 2 x 34 Pin Plastic Connectors
  • 2 x 26 Pin Plastic Connectors
  • Universal Part
