Description

The MoTeC MLS ECU is a derivative of the M4 ECU which has been designed to run a limited range of Chevrolet and Lexus/Toyota V8 engines. The ECU has a limited number of ref/sync modes to suit these engines which need to be wired to run injectors triggered in groups of 2 (Semi-Sequential Group Fire). The MLS has its own version of EMP software which is available from the MoTeC website.

The Chevrolet LS series V8 engine has 8 coils which are configured to run in wasted spark mode. Using an MLS this leaves 1 auxiliary output spare to use as required (fuel pump, fans etc.).

The MLS can also be configured to run the Lexus/Toyota 1UZFE engine with twin distributors. Ignition

outputs are limited to 2 with the remaining 3 Auxiliary outputs available to be used as required.

In all other respects the MoTeC MLS functions in the same way as the MoTeC M4.



Specifications

Motec | 26011 | Engine Management

  • M4 ECU Upgrade

Compatibility

  • Universal Part

The MoTeC MLS ECU is a derivative of the M4 ECU which has been designed to run a limited range of Chevrolet and Lexus/Toyota V8 engines. The ECU has a limited number of ref/sync modes to suit these engines which need to be wired to run injectors triggered in groups of 2 (Semi-Sequential Group Fire). The MLS has its own version of EMP software which is available from the MoTeC website.

The Chevrolet LS series V8 engine has 8 coils which are configured to run in wasted spark mode. Using an MLS this leaves 1 auxiliary output spare to use as required (fuel pump, fans etc.).

The MLS can also be configured to run the Lexus/Toyota 1UZFE engine with twin distributors. Ignition

outputs are limited to 2 with the remaining 3 Auxiliary outputs available to be used as required.

In all other respects the MoTeC MLS functions in the same way as the MoTeC M4.



Motec | 26011 | Engine Management

  • M4 ECU Upgrade
  • Universal Part
