Description



Mishimoto has developed a brand new universal dual pass oil cooler for enthusiasts that demand the most from their vehicles. Keeping oil temperatures in control is crucial for a successful day at the track, street or strip. High engine oil temperatures can promote engine wear and lead to serious internal engine damage. The Mishimoto dual pass cooler is constructed from high pressure internal tubes rated to 120psi and is built to handle the most extreme conditions. The Mishimoto dual pass cooler offers an extremely large surface cooling area thanks to 8mm external fins so you can concentrate more on driving and less on temperatures. These coolers also possess the ability to cool all of your automotive fluids such as transmission and power steering fluid. As with all of our products the Mishimoto dual pass cooler is protected with our signature Lifetime Warranty

  • 25-row dual pass design for optimal fluid temperature reduction
  • Extends life of high-wear engine components
  • 8mm external fins provides large surface cooling area
  • high pressure internal tubes rated to 120psi
  • Can be used to cool transmission and power steering fluid
  • Minimal pressure loss
  • Mishimoto Lifetime Warranty



TECH INFO:

  • Material - 6061 Aluminum
  • Core Height - 10.16"
  • Rows - 25, dual pass
  • Cooler Contruction - Tube-and-Fin
  • Core Thickness - 1.42"
  • Core Length - 11.81"
  • Increase In Oil Capacity - 1.04
  • Overall Height - 14.8"
  • Overall Length - 11.57"
  • Overall Width - 1.77"
  • Core Size - 11.81" x 10.16"
  • Inlet - -10AN
  • Outlet - -10AN



Purchase Includes:

  • Mishimoto Oil Cooler
  • Mishimoto Lifetime Warranty

Specifications

Compatibility

  • Universal Part



Mishimoto has developed a brand new universal dual pass oil cooler for enthusiasts that demand the most from their vehicles. Keeping oil temperatures in control is crucial for a successful day at the track, street or strip. High engine oil temperatures can promote engine wear and lead to serious internal engine damage. The Mishimoto dual pass cooler is constructed from high pressure internal tubes rated to 120psi and is built to handle the most extreme conditions. The Mishimoto dual pass cooler offers an extremely large surface cooling area thanks to 8mm external fins so you can concentrate more on driving and less on temperatures. These coolers also possess the ability to cool all of your automotive fluids such as transmission and power steering fluid. As with all of our products the Mishimoto dual pass cooler is protected with our signature Lifetime Warranty

  • 25-row dual pass design for optimal fluid temperature reduction
  • Extends life of high-wear engine components
  • 8mm external fins provides large surface cooling area
  • high pressure internal tubes rated to 120psi
  • Can be used to cool transmission and power steering fluid
  • Minimal pressure loss
  • Mishimoto Lifetime Warranty



TECH INFO:

  • Material - 6061 Aluminum
  • Core Height - 10.16"
  • Rows - 25, dual pass
  • Cooler Contruction - Tube-and-Fin
  • Core Thickness - 1.42"
  • Core Length - 11.81"
  • Increase In Oil Capacity - 1.04
  • Overall Height - 14.8"
  • Overall Length - 11.57"
  • Overall Width - 1.77"
  • Core Size - 11.81" x 10.16"
  • Inlet - -10AN
  • Outlet - -10AN



Purchase Includes:

  • Mishimoto Oil Cooler
  • Mishimoto Lifetime Warranty
  • Universal Part
